ROUND CABLE WEDGE CLAMPS RKK 01
Cable wedge clamp; Cable diameter: 7.0mm - 11.0mm; Number of cables: 2; Polyamide
ROUND CABLE WEDGE CLAMPS RKK 01
SGD 18.77
/
ROUND CABLE WEDGE CLAMPS RKK 01
SGD 18.77
/
付款与安全
您的支付信息已安全处理。我们不存储信用卡详细信息，也无法访问您的信用卡信息。
Product characteristics
cold resistance
halogen-free
技术属性
一般信息
| Product type | Cable wedge clamp |
| Delivery Unit | 1.000 |
| Weight | 0.204 kg |
电气特性
产品设计
| Number of cables | 2 |
| Overall width | 46.0 |
| Colour | orange |
| Total length | 147.0 |
| For max. cable outer diameter | 11.0 |
| Total height | 52 |
| Material | Polyamide |
| For min. cable outer diameter | 7.0 |
产品特点
| Clamping force (max.) | 343 |
| Halogenfree |
|
认证和标准
文档
Notes
- Photographs and graphics are not to scale and do not represent detailed images of the respective products.
- Unless specified otherwise, the product values shown are rated values at room temperature. You can receive further values, such as tolerances, upon request if they are available and have been released for publication.
- Trade product, not a LAPP product.
产品系列列表
All articles from RKK Round cable wedge clamps
